The 3D surface area.
[Visual Basic .NET] Public ReadOnly Property Area3D As Double
[C#] public double Area3D {get;}
[C++]
HRESULT get_Area3D(
double* Area
);
[C++]Parameters
Area [out, retval] Area is a parameter of type double
Product Availability
Available with ArcGIS Engine, ArcGIS Desktop, and ArcGIS Server.
Remarks
If Patches comprising a MultiPatch geometry have improperly ordered vertices such that positive faces are not pointing outwards, a negative 3D surface area will be returned. To ensure proper orientation, add vertices in a clockwise manner relative to an observer situated outside of the MultiPatch geometry.
[C#]
public static void CalculateArea3D()
{
IGeometry
multiPatchGeometry =
GetMultiPatchGeometry();
IArea3D area3D
= multiPatchGeometry as
IArea3D;
double calculatedArea3D =
area3D.Area3D;
//calculatedArea3D
= 480
}
